Yongsta Large Ash Bucket Heavy-Duty Industrial Vacuum Cleaner
Three - phase Heavy - Duty Industrial Vacuum Cleaner
Industrial Vacuum Cleaner with Upper - Lower Separated Buckets
Continuous - Duty Industrial Vacuum Cleaner
Dust Extraction System
Industrial Vacuum Cleaner for Heavy - Duty Applications
- Overview
- Description
- Applications
- Specifications
- Competitive Advantage
- Recommended Products
| Place of Origin: | China |
| Brand Name: | Yongsta |
| Model Number: | YS-IV-P3.0/YS-IV-P4.0/YS-IV-P5.5/YS-IV-P7.5 |
| Certification: | CE |
| Minimum Order Quantity: | 10 |
| Packaging Details: | Wooden Case Packing |
| Delivery Time: | 20 Days |
| Payment Terms: | 100% payment before production |
| Supply Ability: | 10000 |
Description:
The Three-Phase Upper-Lower Separated Bucket Industrial Vacuum Cleaner is engineered to tackle high-intensity cleaning challenges in industrial settings. Equipped with an industrial-grade three-phase motor, it supports 24/7 uninterrupted operation, eliminating the limitation of frequent shutdowns with traditional vacuums. Its upper-lower separated bucket design enables efficient separation of dust collection and filtration, paired with a large-capacity ash bucket that holds far more dust than standard industrial vacuums—significantly reducing manual dumping frequency and boosting cleaning efficiency.
Featuring a multi-layer high-efficiency filtration system, the vacuum captures materials of all sizes, from large particles to ultra-fine dust, including sawdust, ultra-fine carbon dust, stones, broken glass, and metal shavings. With a filtration precision of 0.3 microns, it effectively controls dust dispersion and helps workshops meet environmental and safety standards. The body is made of cold-rolled steel with an anti-corrosion electrostatic spray coating, resisting harsh industrial environments such as humidity, high temperature, and heavy oil contamination. Its service life is over 50% longer than ordinary equipment.
The upper and lower buckets are connected with quick-release buckles—no tools required. A single person can replace the ash bucket in 30 seconds. It comes with a large-diameter suction port and thickened wear-resistant suction hose, quickly absorbing large particles without clogging. The motor has built-in intelligent overload protection and heat dissipation system, automatically shutting down in case of abnormalities to reduce maintenance costs.
Ideal for metal shavings cleaning in machining workshops, ultra-fine dust collection in carbon/graphite factories, raw material impurity screening in food plants, and cleanroom cleaning in polysilicon workshops. It also fits centralized dust removal needs in factory workshops, cleanrooms, furniture factories, and building materials production lines. It serves as a "dust guard" for fixed workstations and can be used with a mobile cart for flexible full-workshop cleaning.
Applications:
The three-phase upper-lower bucket separated large ash bucket industrial vacuum cleaner is designed for continuous long-time operation. It can absorb a large amount of materials such as dust, particles, sawdust, ultra-fine carbon dust, stones, broken glass and iron filings. It is mainly used in production environments including factory workshops, mechanical processing sites, clean rooms, food factories, carbon factories, graphite factories and polysilicon plants.
Specifications:
| Model | Units | YS-IV-S3600 | YS-IV-P3.0 | YS-IV-P4.0 | YS-IV-P5.5 | YS-IV-P7.5 |
| Volts | V/Hz | 220/50 | 380/50 | 380/50 | 380/50 | 380/50 |
| Power | Kw | 3.6 | 3 | 4 | 5.5 | 7.5 |
| Vacuum | Kpa | 26 | 26 | 28 | 32 | 34 |
| Airflow | m³/h | 430 | 380 | 460 | 520 | 560 |
| Dust Cleaning Method | F/D | Manual | Pull-and-Push Backblowing | Pull-and-Push Backblowing | Pull-and-Push Backblowing | Pull-and-Push Backblowing |
| Filter | Cm³ | 25000 | 29000 | 29000 | 52800 | 52800 |
| Noise | Db(a) | 72 | 68 | 70 | 72 | 73 |
| Suctiner | Mm | 40-50 | 40-60 | 40-60 | 40-60 | 40-60 |
| Volume | L | 70 | 100 | 100 | 100 | 100 |
| Weight | Kg | 42 | 140 | 145 | 149 | 152 |
| Dimensions | Mm | 590*480*1070 | 1100*600*1250 | |||
Competitive Advantage:
1. Super Strong Structural Durability: The bucket body is made of stainless steel, the frame is made of thickened carbon steel square tube, and the casing is made of cold-rolled thickened steel plate with plastic spraying treatment. The triple solid material combination can withstand high-frequency use in industrial scenarios and has a longer service life.
2. Powerful Suction Guarantee: Equipped with high-quality domestic air ring type high-pressure fan as the main power motor, it provides strong suction, efficiently captures various materials such as dust and particles, and meets industrial-grade cleaning needs.
3. Efficient Filtration + Safe and Reliable: Adopts HEPA high-efficiency filter made of polyester fiber coated base material with excellent filtration precision; the electrical control part uses components from well-known domestic brands, providing double guarantees for the safe operation of the equipment and cleaning effect.
4. Convenient Operation Design: Equipped with a quick suction port and an upper-lower bucket separated collection device, making garbage dumping and suction component connection more efficient; the polyurethane silent casters with front fixed and rear universal design make the equipment move flexibly and quietly, adapting to multi-scenario operations in the workshop.
5. Multi-Working Condition Adaptability: Equipped with a variety of quick-connect suction accessories, which can be flexibly switched according to different working conditions and environments, greatly improving the application range of the equipment.
