Yongsta Continuous Bagging Industrial Vacuum Cleaner
Continuous Bagging Industrial Vacuum Cleaner
Industrial Vacuum with Continuous Bagging System
Bagged Continuous-Run Industrial Vacuum
Heavy-Duty Continuous Bagging Vacuum
Continuous Operation Bag Type Industrial Vacuum
Dust Collection Vacuum with Continuous Bagging
Continuous Bagging Vacuum for Dust Control
Industrial Bagging Vacuum for Continuous Production
High-Capacity Continuous Bagging Vacuum
- Overview
- Description
- Applications
- Specifications
- Competitive Advantage
- Recommended Products
| Place of Origin: | China |
| Brand Name: | Yongsta |
| Model Number: | YS-IVCB-S3600 YS-IVCB-P3.0/YS-IVCB-P4.0/YS-IVCB-P5.5/ |
| YS-IVCB-P7.5 | |
| Certification: | CE |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Wooden Case Packing |
| Delivery Time: | 20 Days |
| Payment Terms: | 100% payment before production |
| Supply Ability: | 10000 |
Description:
Three-Phase Continuous Bagging Industrial Vacuum Cleaner is a core dust removal equipment developed specifically for long-term and high-intensity cleaning needs in industrial scenarios. With the core advantages of "uninterrupted continuous operation, high-efficiency dust collection, and more convenient material handling", it completely solves the pain point of frequent shutdowns for ash dumping of traditional industrial vacuum cleaners and builds a stable and efficient cleaning system for various production scenarios.
In terms of structural design, the equipment adopts a three-phase industrial-grade motor combined with a continuous bagging collection system. The motor is equipped with multiple heat dissipation protection devices, which can realize 24-hour uninterrupted continuous operation and maintain stable suction even under working conditions with extremely high dust concentration. The bagging system is equipped with a special filter bag, which supports the quick bag replacement method of "pull and replace". There is zero dust leakage during the replacement process, which not only ensures operation safety but also greatly saves shutdown time and effectively improves production efficiency.
In terms of adsorption performance, relying on the optimized air channel structure and high-efficiency filtration system, the equipment can accurately capture materials of different particle sizes, including ordinary dust, ultra-fine industrial dust, metal iron filings, glass fragments, plastic particles, wood sawdust, carbon powder, graphite powder and other industrial wastes. The suction attenuation rate is less than 5%, and the single dust collection capacity can reach 50-100L (depending on the model), meeting the centralized cleaning needs of large-scale production scenarios.
The equipment also performs excellently in safety and adaptability. It is equipped with multiple safety devices such as overload protection, leakage protection, and anti-clogging alarm, which meets industrial safety standards. The body is made of thick cold-rolled steel plate, and the surface is treated with anti-corrosion spraying, which can adapt to harsh industrial environments such as humidity, high temperature, and heavy oil pollution. It is widely used in mechanical processing workshops, auto parts manufacturing plants, electronic workshops, food processing plants, carbon plants, graphite plants, furniture processing plants, building materials production workshops and other scenarios. It is suitable for both real-time dust removal at fixed stations of the production line and flexible cleaning of the entire workshop with the mobile cart.
Applications:
Continuous bagging industrial vacuum cleaners are suitable for industrial working conditions requiring continuous operation, fine or large amounts of dust, such as carbon/graphite processing, electronic soldering, floor grinding, shot blasting, continuous production lines and dust control.
Specifications:
|
Model |
Units |
YS-IVCB-S3600 |
YS-IVCB-P3.0 |
YS-IVCB-P4.0 |
YS-IVCB-P5.5 |
YS-IVCB-P7.5 |
|
Volts |
V/Hz |
220/50 |
380/50 |
380/50 |
380/50 |
380/50 |
|
Power |
Kw |
3.6 |
3.0 |
4.0 |
5.5 |
7.5 |
|
Vacuum |
Kpa |
26 |
26 |
28 |
32 |
34 |
|
Airflow |
m³/h |
430 |
380 |
460 |
560 |
560 |
|
Dust Cleaning Method |
F/D |
Manual |
Pull-and-Push Backblowing |
Pull-and-Push Backblowing |
Pull-and-Push Backblowing |
Pull-and-Push Backblowing |
|
Filter |
Cm³ |
25000 |
29000 |
29000 |
52800 |
52800 |
|
Noise |
Db(a) |
75 |
65 |
68 |
69 |
72 |
|
Suctiner |
Mm |
40-50 |
40-60 |
40-60 |
40-60 |
40-60 |
|
Volume |
L |
Bagging |
Bagging |
Bagging |
Bagging |
Bagging |
|
Weight |
Kg |
55 |
117 |
123 |
130 |
135 |
|
Dimensions |
Mm |
750*610*1690 |
1130*590*1610 |
|||
Competitive Advantage:
Strong Durability + Intelligent Dust Cleaning：Adopts three-phase centrifugal motor for long-term non-stop operation; optional dust cleaning methods include F backblowing, D electronic or intelligent full-automatic dust cleaning, adapting to different working conditions.
Efficient Filtration + Safety Guarantee：Filter materials can be selected from high-efficiency filter elements or star-shaped polyester fiber needle-punched materials with excellent filtering effect; equipped with automatic pressure relief device that relieves pressure automatically when negative pressure is too high, ensuring safe and reliable operation.
Convenient Dust Collection + Full Automation：Uses continuous bagging for dust collection; optional functions include continuous bagging, full-automatic ash unloading and dust suction; with one-key start design, the whole process is automatic, efficient and worry-free.
Multi-adaptation + Flexible Movement：Provides a full set of accessories with D40/D50/D60 calibers, suitable for various scenarios; equipped with silent casters for light and quick movement.
